Available for | all tricycles
except S-Pedelec | all tricycles
except S-Pedelec | all tricycles
except S-Pedelec | all two- and three-wheelers
except S-Pedelec | Scorpion fs 26 S-Pedelec |
---|
Support | up to 25 km/h (15.6 mph, US-version 20 mph) | up to 25 km/h (15.6 mph, US-version 20 mph) | up to 25 km/h (15.6 mph, US-version 20 mph) | up to 25 km/h (15.6 mph, US-version 20 mph) | up to 45 km/h (28 mph) |
---|
Push assist | up to 6 km/h (3.7 mph) | up to 6 km/h (3.7 mph) | up to 6 km/h (3.7 mph) | up to 4 km/h (2.5 mph) | up to 4 km/h (2.5 mph) |
---|
Reverse gear | – | – | – | up to 3 km/h* (1.8 mph) | – |
---|
Range** | up to 189 km (117 miles)
(up to 463 km / 288 miles with
additional battery, folding function restricted) | up to 177 km (110 miles)
(up to 433 km / 269 miles with
additional battery, folding function restricted) | up to 191 km (118 miles)
(up to 478 km / 297 miles with
additional battery, folding function restricted) | up to 145 km (90 miles)
(up to 290 km / 180 miles with
additional battery, folding function restricted) | up to 60 km (37 miles)
(up to 120 km / 75 miles with
additional battery, folding function restricted) |
---|
Force amplification | 3 levels: Eco / Normal / High | 3 levels: Eco / Normal / High | 3 levels: Eco / Trail / Boost | 5 levels | 5 levels |
---|
Noise level | silent bottom bracket motor | silent bottom bracket motor | very silent bottom bracket motor | extremely silent hub motor | extremely silent hub motor |
---|
Max. torque | 40 Nm (at the front motor) | 60 Nm (at the front motor) | 85 Nm (at the front motor) | 40 Nm (at the rear wheel) | 40 Nm (at the rear wheel) |
---|
Rated power | 250 W | 250 W | 250 W | 250 W | 400 W |
---|
Maximum power | – | – | – | 450 W | 1000 W |
---|
Battery | Shimano 36 V Li-Ion
removable, with lock | Shimano 36 V Li-Ion
removable, with lock | Shimano 36 V Li-Ion
removable, with lock | BMZ 36 V Li-Ion
removable, with lock | BMZ 48 V Li-Ion
removable, with lock |
---|
Capacity | 14 Ah | 14 Ah | 14 Ah | 17 Ah | 13,8 Ah |
---|
Energy content | 418 Wh | 418 Wh | 418 Wh | 612 Wh | 651 Wh |
---|
Battery weight | 2,7 kg (6 lbs) | 2,7 kg (6 lbs) | 2,7 kg (6 lbs) | 3,5 kg (7.7 lbs) | 4,2 kg (9.2 lbs) |
---|
Battery life | 800 – 1000 charging cycles | 800 – 1000 charging cycles | 800 – 1000 charging cycles | 800 – 1000 charging cycles | 800 – 1000 charging cycles |
---|
Charger | Shimano 2 A | Shimano 2 A | Shimano 2 A | BMZ fast charger 4 A | BMZ fast charger 4 A |
---|
Charging time | 6,5 hours (3,5 hours 80%)
without memory effect | 6,5 hours (3,5 hours 80%)
without memory effect | 6,5 hours (3,5 hours 80%)
without memory effect | 4 hours
without memory effect | 4,5 hours
without memory effect |
---|
Charger weight | 1 kg (2.2 lbs) | 1 kg (2.2 lbs) | 1 kg (2.2 lbs) | 0,85 kg (1.9 lbs) | 1,08 kg (2.4 lbs) |
---|
Additional weight | ca. 8,3 kg (18 lbs) | ca. 8,6 kg (18.9 lbs) | ca. 8,2 kg (18.1 lbs) | ca. 8,7 kg (19.2 lbs) | – |
---|
Display | black&white display
above the handlebar grip
(Top View) | black&white display
above the handlebar grip
(Top View) | black&white display
above the handlebar grip
(Top View) | colour display above
the handlebar grip (Top View)
or to the side | colour display above
the handlebar grip (Top View)
or to the side |
---|
Drivetrain | Sram X4 8-speed
derailleur gearing
twist grip
20?: 44/11–34 teeth
26?: 38 / 11–34 teeth | Shimano Nexus Di2 8-speed
rear wheel internal gear hub
20?: 44 / 18 teeth
26?: 44 / 23 teeth | Shimano XT Di2 11-speed
derailleur gearing
with button (electric)
20?: 50 / 11–46 teeth
26?: 44 / 11–46 teeth | Sram 30-speed
derailleur gearing
barend shifters
20?: 60-52-40 / 11–36 teeth
26?: 52-42-30 /11–36 teeth | Sram 30-speed
derailleur gearing
barend shifters
52-42-30 / 11–36 teeth |
---|
Drivetrain
(alternatively) | Shimano Nexus Di2 8-speed
rear wheel internal gear hub | – | Rohloff 14-speed
rear wheel internal gear hub | Pinion C1.12 12-speed
internal gear transmission | Pinion C1.12 12-speed
internal gear transmission |
---|
Extras | optionally with big battery pack (630 Wh) and fast charger (4 A; 2,5 hours: 50%); on option dditional battery (630 Wh)
Bluetooth interface | optionally with big battery pack (630 Wh) and fast charger (4 A; 2,5 hours: 50%); on option dditional battery (630 Wh)
Bluetooth interface | optionally with big battery pack (630 Wh) and fast charger (4 A; 2,5 hours: 50%); on option dditional battery (630 Wh)
Bluetooth interface | Touchscreen; USB interface; Bluetooth interface | Touchscreen; USB interface; Bluetooth interface |
