| Frame | 7005 Series Aluminum, TIG-Welded | 670289 |
| Rear Frame | Rear Frame Unit Split-Axle Cambered | 670290 |
| Rear Unit Hardware | Rear Unit Hardware Kit | 68691 |
| Fork | Full Cro-Mo, Tig Welded | 28547 |
| Headset | Integrated Alloy 28.6x44x30mm Black | 35502 |
| Head/Derailleur Tube Cap | Head/Derailleur Tube Cap | 35511 |
| Handlebar | Steel, Recumbent, Underseat Center Clamp | 33777 |
| Right Handlebar | Right Handlebar Extension USX 22.2mm | 34233 |
| Left Handlebar | Left Handlebar Extension USX 22.2mm | 34232 |
| Stem | Recumbent Ahead w/Steer Tab, UAX Alloy, Black | 58765 |
| Steering Linkage | Eurus UAX Black | 670291 |
| Left Rod End | Left Hand Thread | 68686 |
| Right Rod End | Right Hand Thread | 68685 |
| Grips | EVA Rubber, Locking, 75mm, Black | 32364 |
| Front Brake Lever | Linear Pull, w/Lock, Black/Silver | 12414 |
| Rear Brake Lever | Linear Dual Pull, Black/Silver | 13763 |
| Front Brake | Linear Pull, Black | 12119 |
| Rear brake | Promax Disc Pair w/160mm Rotor | 120145 |
| Front Shifter | SRAM 3.0 3-Speed Grip Shift | 53939 |
| Rear Shifter | SRAM 3.0 8-Speed Grip Shift | 53941 |
| Front Derailleur | Microshift, 31.8 Clamp | 26233 |
| Rear Derailleur | SRAM X4 | 26270 |
| Sprocket | Fixed Sprocket 15mm x 18T | 69370 |
| Freewheel | Sram (8-Speed) 11-32T | 18642 |
| Rear Axle | Rear Axle X3-AX / EURUS Square, fits L or R | 68677 |
| Axle Bearing | Rear Unit Axle Bearing 15idx35od x11w | 6702184 |
| Hub Retaining Bolt | Trike Hub Ret Bolt/Cap for Square or Tapered, Black | 67952 |
| Seat Mesh | R-Type 1-Pc Seat Back Mesh | 50034 |
| Seat Frame | R-Type 1-Pc Alloy, Black | 50033 |
| Seat Pad | R-Type Mesh Open Cell Foam | 50042 |
| Seat Mount | R-Type Alloy, 44.5mm, Black | 50035 |
| Seat Mount Binder | QR M6x60mm Alloy | 50038 |
| Seat Back Pivot Bolt | Seat Mount Pin for R-Type | 50041 |
| Upper Strut | Alloy 150mm Black | 67893 |
| Upper Strut Bolt | M5x35mm | 49672 |
| Upper Strut Washer | Curved Nylon Washer | 49671 |
| Lower Strut | Alloy, Pin Type, 700mm Universal | 50043 |
| Crank Set | Sun, 170x52/42/30, Alloy, Black | 21323 |
| Bottom Bracket | Sealed Cartridge, 68 x 113mm | 22584 |
| Chain | 1/2" x 3/32", (190 Link Total) | 16078 |
| Rear Chain | 1/2 x 1/8"(46 Link Total) | 16248 |
| Chain Guide | Single 38x56x15Wx10D | 16233 |
| Chain Guide Hardware | Guide Wheel Hardware Single 10x47mm | 16182 |
| Chain Tube | Guide Tube | 16236 |
| Chain Tube Bracket | Single Spring w/Hardware | 16240 |
| Chain Tube Clamp | Clamp w/Hardware | 16242 |
| Pedals | Nylon Fiber Body, 9/16" Chromoly Spindle | 41980 |
| Front Hub | Alloy, 36H x 14G with Q/R Axle |
|
| Rear Hub | Trike Alloy, Splined, Disc, Alloy, 36H, Black | 37262 |
| Mid Drive Hub | 135mm Mid-Hub Cassette 8spd |
|
| Front Rim | Double Wall 20" x 1.5-1.75 x 36H, Alloy, Black MSW |
|
| Rear Rim | Double Wall 20" x 1.5-1.75 x 36H, Alloy, Black MSW |
|
| Spokes | 14G Stainless Steel with Brass Nipples, Black |
|
| Front Tire | Kenda Kwest 20 x 1.25", 100psi, Black Wall | 60792 |
| Rear Tire | Kenda Kwest 20 x 1.25", 100psi, Black Wall |
|
